MIL-DTL-14072F
TABLE VIII. Inspection.
Inspection
Requirement Paragraph
Test Paragraph
Paint Finishes
Color
Table II
4.6.1
Type
Table II
4.1.1
Adhesion
3.15
4.6.2
Thickness
Tables I and II
4.6.3
Surface condition
3.15
4.6.5
Spectral reflectance of paint
Table II
4.6.6
films
Plate Finishes
Type
Table III
4.1.1
Thickness
Table III
4.6.3
Hydrogen embrittlement
3.10.2
4.6.4
Surface condition
3.15
4.6.5
TABLE IX. Classification of visual finish defects.
Classification
Defect
Major
Color of paint film not as specified.
Paint film fails to pass adhesion test.
Minimum total paint film thickness is 90 percent of the values specified
See
in Tables I and II.
Paragraph
Maximum total paint film thickness is 120 percent of the values specified
3.15
in Tables I and II.
Paint type not in accordance with applicable specification.
Blisters, nodules, sags, orange peel, chalking, mud cracking or wrinkles
in finished areas visible after assembly.
Spectral reflectance out of limits.
Plating metal not as specified
Plating less than 90 percent of thickness as specified in Table III.
Plating peeling or flaking from underplate or basis metal.
Hydrogen embrittlement of parts.
Scratches, cuts, abrasions, etc. with exposure of bare metal.
Gouge marks, checks, pits, burns with exposure of bare metal.
Foreign debris where removal would expose bare metal.
Minor
Color of paint film as specified, but not within tolerance for shade, hue,
See
or intensity (tolerance in accordance with applicable specification.
Paragraph
Blisters, nodules, sags, orange peel, chalking, mud cracking or wrinkles
3.15
in finished areas are not visible after assembly.
58
